Y
Bay Series
24 Carbon Elite
A sleek, speedy 24-foot bay boat — carbon fiber, vacuum-bagged construction and a 14″ draft built for serious shallow-water fishing.
A sleek, speedy 24-foot bay boat — carbon fiber, vacuum-bagged construction and a 14" draft built for serious shallow-water fishing.
The Yellowfin 24 Carbon Elite is purpose-built for shallow-water fishing without giving up the run. Front and rear casting decks, a comfortable center console and a 50-gallon livewell sit atop a hull built with carbon fiber and vacuum-bagged technology for industry-leading performance. The result is a versatile bay boat that’s quick, dry, light on its feet on the flats and unflinching when the wind picks up.
Carbon Built.
Flats Bred.
24′ 10″
Length
8′ 6″
Beam
14″
Draft
72 gal.
Fuel
425 HP
Max HP
This Model Is Equipped With
Carbon Fiber Hull
Vacuum-bagged carbon fiber construction delivers a hull that’s lighter, stiffer and faster — the foundation of Yellowfin’s industry-leading ride.
01
14" Draft
02
4,120 lb Approx. Weight
03
425 HP Max (Mercury)
04
Single Outboard Rated
Key Benefits
05 Advantages
01
Carbon Fiber Construction
A vacuum-bagged carbon fiber layup yields a stiffer, lighter hull — better hole shot, higher top end and a noticeably drier ride than glass-only builds.
02
Shallow-Water Capable
Just 14 inches of draft, paired with the standard hydraulic jackplate and eight-foot Power-Pole, opens up flats and backcountry most bay boats can’t reach.
03
Front & Rear Casting Decks
Wide-open bow and stern casting platforms give two anglers room to work, with clean rigging and unobstructed sight lines from rail to rail.
04
Tournament-Ready Livewell
A plumbed 50-gallon livewell and release well keep bait fresh and fish lively through a long day — and a 290-quart insulated fish box hauls the catch home.
05
Titanium Hardware
Titanium cleats and through-hulls eliminate corrosion in saltwater for the life of the boat — a small detail that says everything about the build.
Performance
01 / 04
Vacuum-Bagged Carbon Hull
Carbon fiber and vacuum-bagging combine for a hull that’s stiffer, lighter and faster — the core of Yellowfin’s industry-leading performance.
425 HP Mercury Ready
Rated for a single Mercury outboard up to 425 HP for serious top-end speed and effortless hole shot, even with a full livewell and crew.
Hydraulic Jackplate
A standard hydraulic jackplate lets you trim the engine high in skinny water and drop it deep for the run — dialing in the perfect attitude at any speed.
Sleek, Fast Profile
A purpose-built bay hull with a sharp entry and clean exit cuts chop instead of pounding it — keeping the deck dry and the crew fresh.
Standard Features
02 / 04
AmeraTrail Aluminum Trailer
Included AmeraTrail aluminum trailer with electric-over-hydraulic braking makes long tows and steep ramps a non-event.
C-Zone Digital Switching
A C-Zone digital switching system replaces traditional breakers with a clean, configurable touch interface for every circuit on the boat.
Leaning Post & Hydraulic Steering
A purpose-built leaning post and full hydraulic steering deliver all-day comfort and effortless control behind the wheel.
Titanium Cleats & Through-Hulls
Titanium hardware throughout the deck and hull is impervious to saltwater corrosion — a no-compromise detail you’ll appreciate for decades.
Eight-Foot Power-Pole
A standard single eight-foot Power-Pole locks you in place on the flats silently and instantly — without disturbing the fish.
Fishing
03 / 04
Plumbed Livewell & Release Well
A tournament-grade plumbed livewell and dedicated release well keep bait lively and let you score live release points without compromise.
290-Quart Insulated Fish Box
A 290-quart insulated fish box keeps the catch cold from the first bite to the dock — big enough for a full day of action.
10 Console Rod Holders
Ten console-mounted rod holders carry a full spread of rigged rods — ready for whatever the day throws at you.
Front & Rear Casting Decks
Wide, uncluttered bow and stern decks let two anglers work the boat at once with a clean 360° of casting lanes.
Trolling Motor Ready
Option a bow-mount trolling motor with onboard battery charger to silently work shorelines, flats and mangroves all day long.
Notable Options
04 / 04
Canvas T-Top
Add a canvas T-top for lightweight shade, rod storage overhead and a clean line that keeps the boat’s profile low and quick.
Hardtop & Tower Options
Step up to a full hardtop or tower for serious shade, second-station sight fishing and a premium offshore-grade build.
Second Power-Pole
Add a second eight-foot Power-Pole to anchor square in current and lock the bow exactly where you want it on the flats.
Build Your 24
Configure trolling motor, charger, electronics and tower options to spec a 24 Carbon Elite tuned exactly to the way you fish.
Get in Touch
Request More Information
Interested in the 24 Carbon Elite? Send us a message and our team will reach out with details, pricing, and availability.
